Colour

Black, Silver Anodized

Brief Description

The SlideLine 16 Plus is an inset bottom running sliding system that is easy-to-install and comes packed with features like minimum door-to-door gap of 12mm, 30 kg & 50 kg soft-close dampeners, & many more.

Detailed Description

• Twin track design for 2-door or 3-door sliding wardrobes with inset door positioning
• For Door Thickness : 18-22 mm, 22 - 25mm
• Compatible with wooden and aluminium framed doors (55 mm profile only)
• Max door height : 2400 mm
• Door width : 700 mm to 1200 mm
• Profile Length : 2400 mm
• Soft-closing mechanism for smooth operation
• Door height adjustment possible for precise alignment
• Minimum door-to-door gap of 12 mm
• Available with sealing brush / dust strip for door and cover profile for bottom track

Specification

• Door Application : Inset
• Track Length : 2400 mm
• Weight Capacity per Door : 30 Kg, 50kg
• Finish Type : Silver anodised, Black
• For Door thickness : 18 - 22 mm, 22- 25mm
• Closing Functionality : Soft Closing
• No of Cycle Tested : 20000 cycles
• Maximum Door Width : 1200 mm
• Sliding Type : Bottom Running
• Maximum Door Height : 2400 mm
• Door Material : Wood / Aluminium frame door
• Unit : Set
• Opening Optional : Soft Opening
• Cover profile : Included in packaging
• No of Doors : 2 Doors , 3Doors
• Net Quantity : 1 Set
• Name of the Manufacturer/Importer : Hettich India Private Limited
• Country of Origin : India

Warranty

5 Years

(The warranty given is Functional warranty* of the product. Please refer the Warranty TAB under policy information for Surface warranty*)

Do’s & Don’ts for Hettich Hinges

Do’s

• Fix any sliding fitting as per company specified dimensions and procedure.
• Use high quality screws to fix the running tracks & accessories so the rusting doesn’t happen on screws and spread over the track & accessories.
• Make sure about the running & guide track should be aligned properly while installing.
• Clean the running track, guide profiles or any accessories with dry clothes only.
• While installing make sure that the coating is not damaged.

Don’ts

• Don’t use any type of chemical for cleaning the running track, guide profiles or any accessories.
• Don’t disassemble the fitting unless required.
• Don’t use any type of lubricants in fitting.
• Do not put paint on the fitting.
